Total products found: 3483
Click the Name: or Part #: below to see more. Order by: Part or Name
|  Faceplate  Plate  Switch 1  Switch 2  Switch 3  Switch 4  Switch 7 | Plate Name: Part #: FAC-02719, Starcraft Bus by Forest River, Inc. Documents: RCT-02719-0__00 Stracraft.pdfSwitch 1 Name: "DOOR-OPEN-CLOSE" Black Switch Cap dual White Lens (ON)-OFF-(ON) Part #: C-00009-10-0V8D Documents: C-00009-10-0V8D,
Black Cap dual White Lens "Open-Door-Close" pdf
RCT Switch Legend, Cap Type & Switch Body, Part Number System
OPTIONAL SWITCH CAPS.
-
00 - Black Cap, single White Lens
-
01 - White Cap, single White Lens
-
02 - Grey Cap, single White Lens
-
03 - Red Cap, single White Lens
-
04 - Yellow Cap, single White Lens
-
05 - Green Cap, single White Lens
-
06 - Black Cap, single White Lens
-
10 - Black Cap, dual White Lens
-
12 - Grey Cap, dual White Lens
-
13 - Red Cap dual White Lens
-
14 - Yellow Cap, dual White Lens
-
15 - Green Cap, dual White Lens
-
16 - Black Cap, dual White Lens
-
20 - Rubber, Black Cap, single Orange Lens
-
23 - Rubber, Red Cap, single Orange Lens
-
30 - Rubber Black Cap, dual Orange Lens
OPTIONAL CARLING SWITCH BODYS.
-
0V1D - Carling Switch Body ON-OFF, Maintained
-
0V2D - Carling Switch Body, (ON)-OFF, Momentary
-
0V4D - Carling Super Bright, Orange, ON-OFF, Maintained Locking
-
0V6D - Carling Switch Body, ON-OFF-ON, Maintained
-
0V8D - Carling Switch Body, (ON)-OFF-(ON), Momentary Switch 1 Legend: Blank Legend Switch 2 Name: "INTERIOR LIGHT" Black Switch Cap single White Lens ON-OFF Part #: C-00013-00-0V1D Documents: C-00013-00-0V1D
