Plate Name: Ambulance Module & Code Switch
Part #: FAC-02756, Southern Emergency Consultants
Documents:
RCT-02756-0__00 Southern Emergency Consultants.pdfCable 1 Name: Blank Cable
Switch 1 Name: "MODULE MASTER" Grey Switch Cap single White Lens (ON) OFF
Part #: C-00556-02-0V2D
Documents: C-00556-02-0V2D Module Master.pdf Switch 1 Legend: Blank Legend
Switch 2 Name: "LEFT DOME HIGH LOW" Black Switch Cap dual White Lens (ON)-OFF-(ON)
Part #: C-00562-10-0V8D
Documents: C-00562-10-0V8D LEFT DOME HIGH LOW.pdf Switch 2 Legend: Blank Legend
Switch 3 Name: "RIGHT DOME HIGH LOW" Black Switch Cap dual White Lens (ON)-OFF-(ON)
Part #: C-00563-10-0V8D
Documents: C-00563-10-0V8D RIGHT DOME HIGH LOW.pdf Switch 3 Legend: Blank Legend
Switch 4 Name: "ATTENDANT LIGHT" Black Switch Cap single White Lens (ON) OFF
Part #: C-00564-00-0V2D
Documents: C-00564-00-0V2D ATTENDANT LIGHT.pdf Switch 4 Legend: Blank Legend
Switch 5 Name: "CODE RED" Red Switch Cap single White Lens ON- OFF
Part #: C-00565-03-0V1D
Documents: C-00565-03-0V1D CODE RED.pdf Switch 5 Legend: Blank Legend
Switch 6 Name: "CODE AMBER" Yellow Switch Cap single White Lens ON- OFF
Part #: C-00566-04-0V1D
Documents: C-00566-04-0V1D CODE AMBER.pdf Switch 6 Legend: Blank Legend
Switch 7 Name: "CODE GREEN" Green Switch Cap Single White Lens ON-OFF
Part #: C-00567-05-0V1D
Documents: C-00567-05-0V1D CODE GREEN.pdf Switch 7 Legend: Blank Legend
Switch 8 Name: "CODE BUZZER" White Switch Cap single White Lens (ON) OFF
Part #: C-00568-01-0V2D
Documents: C-00568-01-0V2D CODE BUZZER.pdf Switch 8 Legend: Blank Legend
Switch 9 Name: "EXHAUST FAN" Black Switch Cap Single White Lens (ON) OFF
Part #: C-00569-00-0V2D
Documents: C-00569-00-0V2D EXHAUST FAN.pdf Switch 9 Legend: Blank Legend
Switch 10 Name: "INVERTER" Black Switch Cap Single White Lens (ON) OFF
Part #: C-00570-00-0V2D
Documents: C-00570-00-0V2D INVERTER.pdf Switch 10 Legend: Blank Legend
Switch 11 Name: "OXYGEN LIGHT" Black Switch Cap Single White Lend (ON) OFF
Part #: C-00580-00-0V2D
Documents: C-00580-00-0V2D OXYGEN LIGHT.pdf Switch 11 Legend: Blank Legend
Switch 12 Name: "FLUORESCENT" Black Switch Cap Single White Lens (ON) OFF
Part #: C-00571-00-0V2D
Documents: C-00571-00-0V2D FLUORESCENT.pdf Switch 12 Legend: Blank Legend
Switch 13 Name: "SUCTION" Yellow Switch Cap Single White Lens (ON) OFF
Part #: C-00572-04-0V2D
Documents: C-00572-04-0V2D SUCTION.pdf Switch 13 Legend: Blank Legend
Switch 14 Name: "CLIMATE HEATING COOLING" Black Switch Cap Double White Lens ON-OFF-ON
Part #: C-00573-10-0V6D
Documents: C-00573-10-0V6D CLIMATE HEATING COOLING.pdf Switch 14 Legend: Blank Legend
Switch 15 Name: "FAN HIGH FAN LOW FAN MED" Black Switch Cap Double White Lens ON-OFF-ON
Part #: C-00574-10-0V6D
Documents: C-00574-10-0V6D FAN HIGH FAN LOW FAN MED.pdf Switch 15 Legend: Blank Legend
Switch 16 Name: Blank Switch
Power Center 1 Name: Ambulance Power Center, Plug-In-Play
Part #: RCT-01479-00000
Documents: RCT-01479-00000, Ambulance Power Center Plug-In-Play. Ambulance Power Center, EPC-7, Plug-In-Play.
20 Ampere Circuit Breakers on all outputs.
COMPLETE SYSTEM REQUIRES :
Ambulance Dash Switch Panel, PCB-00745.
Ambulance Module Switch Panel, PCB-01003 or PCB-01334.
DAT-01352-00XX0 (30 conductor data cable, XX dipicts length).
DAT-01351-00XX0 (25conductor data cable, XX dipicts length).
Power Center 2 Name: Ambulance Power Center, Plug-In-Play
Part #: RCT-01479-00001
Documents: RCT-01479-00001, Ambulance Power Center Plug-In-Play. Ambulance Power Center, EPC-7, Plug-In-Play.
A B C Body Flasher, RCT-00772-00000.
External Compartment Control, RCT-00450-00000.
20 Ampere Circuit Breakers on all outputs.
COMPLETE SYSTEM REQUIRES :
Ambulance Dash Switch Panel, PCB-00745.
Ambulance Module Switch Panel, PCB-01003 or PCB-01334.
DAT-01352-00XX0 (30 conductor data cable, XX dipicts length).
DAT-01351-00XX0 (25conductor data cable, XX dipicts length).
Power Center 3 Name: Ambulance Power Center, Plug-In-Play
Part #: RCT-01479-00002
Documents: RCT-01479-00002, Ambulance Power Center Plug-In-Play.
Ambulance Power Center, EPC-7, Plug-In-Play.
External Compartment Control, RCT-00450-00000.
20 Ampere Circuit Breakers on all outputs.
COMPLETE SYSTEM REQUIRES :
Ambulance Dash Switch Panel, PCB-00745.
Ambulance Module Switch Panel, PCB-01003 or PCB-01334.
DAT-01352-00XX0 (30 conductor data cable, XX dipicts length).
DAT-01351-00XX0 (25conductor data cable, XX dipicts length).
Power Center 4 Name: Ambulance Power Center, Plug-In-Play
Part #: RCT-01479-00003
Documents: RCT-01479-00003, Ambulance Power Center Plug-In-Play.
Ambulance Power Center, EPC-7, Plug-In-Play.
A B C Body Flasher, RCT-00772-00000.
20 Ampere Circuit Breakers on all outputs.
COMPLETE SYSTEM REQUIRES :
Ambulance Dash Switch Panel.
Ambulance Module Switch Panel.
DAT-01352-00XX0 (30 conductor data cable, XX dipicts length).
DAT-01351-00XX0 (25conductor data cable, XX dipicts length).
